Database imports

Overview

You can import an existing internet-accessible MySQL database into a PlanetScale Vitess database with no downtime. An import has two parts:

An external keyspace connects your production branch to your existing MySQL database.
A Vitess MoveTables workflow copies the tables from the external keyspace into a PlanetScale keyspace, keeps them in sync while your application keeps running, and switches traffic to PlanetScale when you’re ready.

You run the import with the pscale CLI. The Workflows page in the dashboard shows the progress of the import, but it is read-only: every step on this page is a CLI command.

You must be an Organization Administrator or a Database Administrator of the database to run an import. To run an import with a service token, give it the create_branch, read_workflow, write_workflow, and delete_workflow permissions on the database, plus delete_production_branch to delete the external keyspace at the end.

Before you begin, it may be helpful to check out our general MySQL compatibility guide.

Import process overview

Prepare your source database - Check its server settings, create a user for PlanetScale, and allow PlanetScale’s IP addresses
Create your PlanetScale database - Create the Vitess database you are importing into
Create an external keyspace - Connect the production branch to your source database. PlanetScale checks connectivity, server settings, user grants, and schema compatibility first
Start the import - Create a MoveTables workflow from the external keyspace to your PlanetScale keyspace
Monitor the import - Watch the copy and replication progress, then verify the data
Connect your application to PlanetScale - Test your application against PlanetScale while your source database is still serving traffic
Switch traffic - Move reads, then writes, to PlanetScale
Complete the import - Stop replication and disconnect your source database

It’s recommended to avoid all schema changes / DDL (Data Definition Language) statements during an import on both your source database and the PlanetScale database. This includes CREATE, DROP, ALTER, TRUNCATE, etc.

The examples on this page import a MySQL database named commerce into a PlanetScale database named commerce in the acme organization.

Step 1: Prepare your source database

Server configuration

These server settings need to be set correctly for the import to work:

Variable	Required value	Documentation
`gtid_mode`	`ON`	Documentation
`log_bin`	`ON`	Documentation
`binlog_format`	`ROW`	Documentation
`binlog_row_image`	`FULL` or `NOBLOB`	Documentation
`expire_logs_days`*	`>= 2`	Documentation
`binlog_expire_logs_seconds`*	`>= 172800`	Documentation
`sql_mode`	Includes `NO_ZERO_IN_DATE` and `NO_ZERO_DATE`, and does not include `ANSI_QUOTES`	Documentation
`max_connections`	`>= 10`	Documentation

* Either expire_logs_days or binlog_expire_logs_seconds needs to be set. If both are set, binlog_expire_logs_seconds takes precedence. On Amazon RDS and Aurora, set binlog retention hours to at least 48 instead. See the provider-specific migration guides for how to change these settings. MySQL 5.6, 5.7, and 8.0 are supported. The source database must not already contain a _vt database.

Create a user for PlanetScale

PlanetScale connects to your source database with a single user. That user needs replication privileges, read and write access to the database you’re importing, and access to the ps_import_* database that PlanetScale creates on your source to track replication. See Import user permissions for the full list of grants and a script that creates the user.

Allow PlanetScale’s IP addresses

Allow connections from PlanetScale’s IP addresses for your database’s region in your database firewall or security group. See Import public IP addresses for where to find them.

Step 2: Create your PlanetScale database

Create the Vitess database you’re importing into:

pscale database create commerce --org acme --region us-east --cluster-size PS_10 --wait

Pick a region close to your source database and a cluster size with enough storage for your data. You can also create the database from the dashboard with “New database” > “Create database”. We recommend using the same name as the database you’re importing from to avoid updating any database name references throughout your application code. Your PlanetScale database starts with one keyspace, named after the database. That keyspace is the target of the import. If you’d prefer to use a different database name, make sure to update your app where applicable once you fully switch over to PlanetScale.

Step 3: Create an external keyspace

An external keyspace connects your production branch to your source database. It is the source of the import. Give it a name that is different from your PlanetScale keyspace, such as commerce_source.

Connection settings

Setting	`pscale keyspace create-external` flag	Description
Host name	`--host`	The address where your database is hosted.
Port	`--port`	The port where your database is hosted. The default MySQL port is `3306`.
Database name	`--source-database`	The exact name of the database you want to import on your MySQL server.
Username	`--username`	The user you created for PlanetScale.
Password	`--password`	The password for that user.
SSL verification mode	`--ssl-mode`	`disabled`, `preferred`, `required`, `verify_ca`, or `verify_identity`.
SSL client certificate and key	`--ssl-client-certificate`, `--ssl-client-key`	Authenticate with mTLS instead of a password. Pass the PEM contents or a path to a PEM file.
SSL CA certificate chain	`--ssl-certificate-authority`	If your database server has a certificate with a non-trusted root CA, provide the full CA certificate chain here.
SSL server name override	`--ssl-server-name`	Override the server name for SSL certificate verification.
Minimum TLS version	`--min-tls-version`	The oldest TLS version PlanetScale may use. The default is TLS 1.2.

If your database server has a valid SSL certificate, set the SSL verification mode to required or higher. For more information about certificates from a Certificate Authority, check out our Secure connections documentation.

Check your source database

Run create-external with --dry-run to check your source database without creating anything:

pscale keyspace create-external commerce main commerce_source \
  --org acme \
  --host db.example.com \
  --source-database commerce \
  --username migration_user \
  --password <PASSWORD> \
  --ssl-mode required \
  --dry-run

PlanetScale checks:

Connectivity - It can connect with the credentials and SSL/TLS settings you provided.
Server configuration - The server settings above are correct.
User grants - The user has the required grants.
Schema compatibility - Every table can be imported. See Schema compatibility below.

If PlanetScale cannot connect, or the server settings or grants are wrong, it won’t create the external keyspace. Fix the issue on your source database and run the check again. The Import troubleshooting guide covers each error.

Schema compatibility

The check also reports tables that can’t be imported:

Missing unique key - All tables must have a unique, not-null key. See our Changing unique keys documentation for more info.
Invalid charset - We support utf8, utf8mb4, utf8mb3, latin1, and ascii. Tables with other charsets will be flagged.
Unsupported storage engines - Only InnoDB is supported.
Unsupported partitioning - Only RANGE partitioning is supported, without subpartitions.

Schema errors don’t stop you from creating the external keyspace. Fix those tables on your source database, or leave them out of the import with --exclude-tables in the next step. If your database uses foreign key constraints, PlanetScale turns on foreign key support for your PlanetScale database when you create the external keyspace. See Foreign key constraints before you start the import.

Create the external keyspace

Once the check passes, run the same command with --wait instead of --dry-run:

pscale keyspace create-external commerce main commerce_source \
  --org acme \
  --host db.example.com \
  --source-database commerce \
  --username migration_user \
  --password <PASSWORD> \
  --ssl-mode required \
  --wait

PlanetScale sizes the external keyspace from the size of your source data. You can also create the external keyspace from the dashboard: open your production branch, click “Clusters”, then “New keyspace” > “Create external keyspace”. The form checks your source database the same way before it creates the keyspace, and lists the IP addresses to allow.

Step 4: Start the import

Create a MoveTables workflow that copies the tables from the external keyspace into your PlanetScale keyspace:

pscale branch vtctl move-tables create commerce main \
  --org acme \
  --workflow import_commerce \
  --source-keyspace commerce_source \
  --target-keyspace commerce \
  --all-tables \
  --defer-secondary-keys \
  --format json

The workflow starts right away. You will pass the workflow name and the target keyspace to every later command.

Import options

Tables - --all-tables imports every table. To import only some tables, pass --tables with a comma-separated list instead. To import every table except a few, combine --all-tables with --exclude-tables.
Defer secondary index creation - --defer-secondary-keys creates secondary (non-primary) indexes after the data is copied instead of during the copy. Maintaining many indexes while inserting data is slow, so this can make your import significantly faster (often 2-3x faster for tables with multiple indexes). Secondary indexes are created during the copy unless you pass this flag. Don’t use it if your database has foreign key constraints.
DDL handling - --on-ddl controls what happens if schema changes (like ALTER TABLE, ADD INDEX, etc.) run on your source database while the import is running:
- STOP (default, recommended) - The workflow stops when a schema change is detected. After you review the change, restart the workflow with pscale branch vtctl move-tables start. This is the safest option because it lets you verify the schema changes won’t cause issues before continuing.
- IGNORE - Schema changes are skipped and won’t be applied to your PlanetScale database. Your import continues without interruption, but your schemas will diverge. Only use this if you’re confident you don’t need these changes or plan to apply them manually to your PlanetScale database later.
- EXEC - Schema changes are applied to your PlanetScale database while the import continues running. If applying a schema change fails (for example, if it’s not compatible with Vitess), the workflow stops and you’ll need to restart it.
- EXEC_IGNORE - Attempts to apply schema changes but keeps running even if they fail.

EXEC_IGNORE can lead to schema mismatches between your external database and PlanetScale database, potentially causing data inconsistencies or unexpected behavior. Only use this if you understand the risks and have a plan to handle failures.

See the move-tables reference for every option.

Foreign key constraints

If your database uses foreign key constraints:

Import all tables - Pass --all-tables without --exclude-tables so referential integrity stays intact.
Use an atomic copy - Pass --atomic-copy, and don’t pass --defer-secondary-keys. Foreign key constraints need their indexes to exist during the copy.
Import retries - An atomic copy holds a long-running transaction on your source database, which can increase load. If it fails, it starts over from the beginning instead of resuming where it left off.

pscale branch vtctl move-tables create commerce main \
  --org acme \
  --workflow import_commerce \
  --source-keyspace commerce_source \
  --target-keyspace commerce \
  --all-tables \
  --atomic-copy \
  --format json

For more information about foreign key support and limitations, see our foreign key constraints documentation.

Step 5: Monitor your import

Check the progress of the import with status:

pscale branch vtctl move-tables status commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --format json

The output shows:

table_copy_state - Rows and bytes copied so far for each table that is still copying
shard_streams - Each replication stream’s state and any error message
traffic_state - Whether reads and writes have switched to PlanetScale

Streams are Copying while the initial data is copied, then Running once the import is replicating new changes from your source database. A Lagging stream is running but hasn’t caught up with recent changes. A Stopped or Error stream includes a message that explains why. The output also includes a next_steps field with the command to run next. You can also follow the import in the dashboard. Click “Workflows” in the left nav, select your production branch, and open the workflow to see its streams, per-table copy progress, replication lag, and traffic routing. To pause the import, run pscale branch vtctl move-tables stop. Run pscale branch vtctl move-tables start to resume it.

Verify data (optional)

Once the copy completes and the streams are Running, you can verify that the data in PlanetScale matches your source database with a VDiff:

pscale branch vtctl vdiff create commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --format json

The output includes the VDiff’s uuid. Pass it to vdiff show and repeat until the VDiff completes:

pscale branch vtctl vdiff show commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --uuid <VDIFF_UUID> \
  --format json

The dashboard also shows the VDiff’s progress on the workflow page. If the VDiff reports mismatches, don’t switch traffic until you’ve resolved them.

Step 6: Connect your application to PlanetScale

Once the streams are Running, you can connect your application to PlanetScale while your source database stays the authoritative source. Until you switch traffic, PlanetScale routes queries for the imported tables to your source database through the external keyspace, so reads and writes still happen there. Create a password for your production branch and point a test deployment of your application at PlanetScale. This is the ideal time to test your application end-to-end before switching traffic.

Step 7: Switch traffic

When you’re ready, switch traffic to PlanetScale. You can switch replica traffic first to test reads, then switch primary traffic.

Switch replica traffic - Serve read queries sent to replicas from PlanetScale while writes still go to your source database. This is an optional intermediate step that lets you test read traffic separately.

pscale branch vtctl move-tables switch-traffic commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --tablet-types REPLICA,RDONLY \
  --format json

Switch primary traffic - Serve both reads and writes from PlanetScale.

pscale branch vtctl move-tables switch-traffic commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --tablet-types PRIMARY \
  --format json

Pass --dry-run to see what a switch would do without applying it.

Critical: Update connection strings before switching primary trafficYou must update your application’s connection string to point to PlanetScale before switching primary traffic. If you switch primary traffic while your application is still connected to your external database, you will create a split-brain scenario where:

PlanetScale believes it is serving all traffic (reads and writes)
Your application continues writing to the external database
The two databases diverge, causing data inconsistency and potential data loss

Always verify your application is connected to PlanetScale before proceeding with the primary traffic switch.

After primary traffic switches, PlanetScale replicates writes back to your source database, so both stay in sync until you complete the import. If something goes wrong, switch traffic back to your source database:

pscale branch vtctl move-tables reverse-traffic commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --format json

Step 8: Complete the import

Once you’ve switched all traffic to PlanetScale and verified everything is working:

Monitor your application for any issues. Check:

Application logs for errors
Replication lag (should be near zero)
Error tracking tools
Application performance metrics

Preview what completing the workflow will do:

pscale branch vtctl move-tables complete commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --keep-data=true \
  --keep-routing-rules=false \
  --dry-run \
  --format json

When you’re confident everything is working correctly, run the same command without --dry-run.

Delete the external keyspace to disconnect PlanetScale from your source database:

pscale keyspace delete commerce main commerce_source --org acme

--keep-data must be true when you complete an import. Your source database’s tables are never dropped or renamed. --keep-routing-rules=false removes the routing rules that sent queries to the external keyspace. Write both flags with an =: a space-separated value such as --keep-data false is read as --keep-data=true. What happens when you complete:

Replication from PlanetScale back to your source database stops
The routing rules for the imported tables are removed
The workflow no longer appears on the Workflows page

What happens when you delete the external keyspace:

PlanetScale disconnects from your source database
The source database’s credentials are removed from PlanetScale

ImportantCompleting the workflow is not reversible. Make sure your application is running smoothly on PlanetScale before completing the import. Don’t delete the external keyspace until the workflow is complete.

Once the import is complete, you can drop the ps_import_* database from your source database and remove the user you created for PlanetScale.

Cancel an import

To stop an import before you complete it, cancel the workflow:

pscale branch vtctl move-tables cancel commerce main \
  --org acme \
  --workflow import_commerce \
  --target-keyspace commerce \
  --keep-data=false \
  --keep-routing-rules=false \
  --format json

--keep-data=false deletes the data already copied into your PlanetScale keyspace. The external keyspace stays connected, so you can fix the problem and start a new workflow. Delete the external keyspace if you don’t plan to try again.

Next steps

You just migrated your database to PlanetScale. Here are some things you can do next:

Create a development branch - Use branching in your development workflow.
Create a deploy request - Test schema changes in dev branches before pushing to production.

Provider-specific migration guides

For detailed instructions on preparing your external database for import, see our provider-specific guides:

Troubleshooting

For detailed troubleshooting guidance, see our Import troubleshooting guide.

Need help?

Get help from the PlanetScale Support team, or join our Discord community to see how others are using PlanetScale.

Pricing

Platform

Integrations

Guides

Overview

Import process overview

Step 1: Prepare your source database

Server configuration

Create a user for PlanetScale

Allow PlanetScale’s IP addresses

Step 2: Create your PlanetScale database

Step 3: Create an external keyspace

Connection settings

Check your source database

Schema compatibility

Create the external keyspace

Step 4: Start the import

Import options

Foreign key constraints

Step 5: Monitor your import

Verify data (optional)

Step 6: Connect your application to PlanetScale

Step 7: Switch traffic

Step 8: Complete the import

Cancel an import

Next steps

Provider-specific migration guides

Troubleshooting

Need help?

​Overview

​Import process overview

​Step 1: Prepare your source database

​Server configuration

​Create a user for PlanetScale

​Allow PlanetScale’s IP addresses

​Step 2: Create your PlanetScale database

​Step 3: Create an external keyspace

​Connection settings

​Check your source database

​Schema compatibility

​Create the external keyspace

​Step 4: Start the import

​Import options

​Foreign key constraints

​Step 5: Monitor your import

​Verify data (optional)

​Step 6: Connect your application to PlanetScale

​Step 7: Switch traffic

​Step 8: Complete the import

​Cancel an import

​Next steps

​Provider-specific migration guides

​Troubleshooting

​Need help?

Overview

Import process overview

Step 1: Prepare your source database

Server configuration

Create a user for PlanetScale

Allow PlanetScale’s IP addresses

Step 2: Create your PlanetScale database

Step 3: Create an external keyspace

Connection settings

Check your source database

Schema compatibility

Create the external keyspace

Step 4: Start the import

Import options

Foreign key constraints

Step 5: Monitor your import

Verify data (optional)

Step 6: Connect your application to PlanetScale

Step 7: Switch traffic

Step 8: Complete the import

Cancel an import

Next steps

Provider-specific migration guides

Troubleshooting

Need help?
